ZRH-134N – 4X Shock Reduced Air Riveting Hammer

Professional Heavy-Duty Riveting Solution

The ZRH-134N 4X Shock-Reduced Air Riveting Hammer is a high-performance pneumatic riveting tool designed for use in aerospace, automotive, shipbuilding, and heavy industrial applications. Designed with advanced vibration and shock-reduction technology, this riveting hammer delivers powerful blows with reduced operator fatigue, making it ideal for continuous production and precision riveting tasks.

Key Features

• Shock Reduction Technology – Minimizes vibration and recoil impact, reducing operator fatigue and risk of Hand-Arm Vibration Syndrome (HAVS).

• 4X Riveting Power – Delivers the strength required for medium to large rivets, ensuring consistent set quality.

• Durable Industrial Design – Constructed with high-strength alloys for long tool life under demanding use.

• Ergonomic Grip – Provides excellent handling, comfort, and control during extended operation.

• Quick-Change Retainer – Enables fast and secure rivet set changes, enhancing workflow efficiency.

• Precision Performance – Ensures uniform rivet formation for structural integrity and professional finish.

Technical Specifications

• Model: ZRH-134N

• Type: 4X Shock-Reduced Riveting Hammer

• Blows per Minute (BPM): Approx. 2,000

• Stroke Length: 2-1/4 in. (57 mm)

• Air Inlet: 1/4 in. NPT

• Recommended Air Pressure: 90 PSI (6.2 bar)

• Rivet Capacity: 3/32 in. – 1/4 in. aluminum or mild steel rivets

• Weight: Approx. 5.3 lbs (2.4 kg)

• Vibration Control: Integrated anti-shock system

Benefits

Reduced Fatigue – Shock-absorbing design lowers vibration exposure for safer, longer use.
High Productivity – 4X riveting power drives large rivets quickly and efficiently.
Durability You Can Trust – Built to withstand continuous industrial workloads.
Operator Comfort – Ergonomic grip and balanced body reduce strain during extended tasks.
Precision Riveting – Delivers strong, consistent rivet heads for critical structural applications.

Applications

• Aerospace Assembly: Ideal for wing, fuselage, and structural riveting.

• Automotive & Heavy Equipment: Ideal for riveting chassis, frames, and body panels.

• Shipbuilding & Rail Industry: Heavy-duty rivet driving in large-scale assemblies.

• Metal Fabrication: Ensures strong and reliable joint fastening.

• Maintenance & Repair Operations (MRO): Suitable for field repairs and rework tasks.

Why Choose the ZRH-134N?

The ZRH-134N 4X Shock-Reduced Air Riveting Hammer is designed for professionals who demand power, precision, and safety in their riveting tools. By integrating shock-reduction technology, it enhances operator comfort and tool control while maintaining maximum riveting efficiency. Whether in aerospace, automotive, shipbuilding, or heavy industrial work, the ZRH-134N ensures consistent, high-quality riveting performance with reduced fatigue.

Features

• Designed with the following patents to ensure the best shock reduction and operator’s comfort.
  1) Portable pneumatic tool assembled with module units.
  2) Suspension vibration-reducing means for portable pneumatic tools.
• Alloy steel-made impact parts are heat-treated for durability.
• The spool valve allows slow, heavy blows needed to drive rivets.
• Ergonomic handle with a rubber-made exhaust muffler for added operator comfort.
• An optional patented universal swivel air inlet joint for the best maneuverability of the tool.

• Air inlet tube
• Bumper
• Valve seat
• Air actuating valve
• Auxiliary damping spring
• Ergonomic handle with rubber sleeve

Features

• Patented Shock-Reduced Mechanism.
• Low vibration design to prevent the operator’s injury after long-term use.
• Ergonomic handle with a rubber-made exhaust muffler for added operator comfort.
• An optional patented Universal Swivel Air Inlet Joint for the best maneuverability of the tool.
  Use for the aerospace & general automotive industries, among others.

ZRH-134NK

[ KIT Contents ]

• CA132901 X1
• CA132902 X1
• CA132903 X1
• CA132904 X1
• CA132905 X1
• 192902 Retainer Spring X1

Specification:

• Chisel Shank Opening: 0.401(10.2) inch(mm)
• Bore Diameter: 1/2(12.7) inch(mm)
• Stroke Length: 3-1/16(77.8) inch(mm)
• Blows Per Minute: 1740 bpm
• Operating Air Pressure: 90(6.2) PSI(bar)
• Avg. Air Cons.: 7.42(210) cfm(l/min)
• Net Weight: 3.7(1.7) lbs(kgs)
• Vibration: 6 m/s²
• Rivet Size: 3/16 Steel
• Rivet Size: 1/4 inch(mm)

For ZRH-132P, ZRH-132PAP, ZRH-132S, ZRH-133P, ZRH-133PAP, ZRH-133S, ZRH-134P, ZRH-134PAP, ZRH-134S, ZRH-132N, ZRH-133N, ZRH-134N

• Round 10.18mm
• Material SCM440 Alloy
• Hardness: 48~51º

192902

Optional

192903 132914
