ZAG-341 90° 2 inch Air Angle Grinder

ZAG-341 – 90° 2-Inch Air Angle Grinder

The ZAG-341 Air Angle Grinder is a compact and efficient pneumatic angle grinder with a 90° head designed for enhanced control and maneuverability. Built for precision work, it’s ideal for tight-space finishing tasks in automotive, metalworking, and industrial maintenance applications.

Technical Specifications

• Motor Power: 0.5 HP

• Grinding Wheel Size: 2 inches (50 mm)

• Free Speed: 15,000 RPM

• Net Weight: 1.5 lbs (0.7 kg)

• Length: 7 inches (178 mm)

• Air Inlet Size: ¼″ NPT / PT

• Minimum Hose Size: ⅜″ (10 mm)

• Average Air Consumption: 3.5 CFM

Key Features & Benefits

• Ergonomic 90° Angle Head — Enhances comfort and allows precise operation in confined or angled spaces.

• Cushion-Grip Handle — Minimizes vibration and cold transfer, reducing operator fatigue.

• Power/Speed Regulator — Lets you adjust RPM easily to match material type and task.

• Rear Exhaust Design — Keeps airflow and debris away from the user and the workpiece.

• Twin-Bearing Spindle — Offers ultra-precise rotation alignment (concentricity of <0.05 mm) and minimizes vibration.


Applications

• Automotive Work — Ideal for precise metal finishing and deburring in confined panel or engine spaces.

• Metal Fabrication — Efficient for cleaning welds, preparing surfaces, and polishing metal contours.

• Industrial Maintenance — Excellent for detail work in compact machinery or equipment areas where full-size grinders won’t fit.

Why Choose the ZAG-341?

If you’re looking for a compact, powerful, and highly controllable angle grinder, the ZAG-341 is the ideal choice. Its combination of a high-speed motor, ergonomic design, precision spindle, and adjustable speed makes it a go-to for demanding, fine-detail tasks in tight or complex work environments.

• Ergonomic cushion-grip handle-Insulates against cold temperature in the hand, helps ease user fatigue, and insulates against vibration.
• Power/Speed Regulator-Allows for easy rpm adjustment.
• Rear exhaust-Directs the exhaust away from the user and the working areas.
• Twin-Bearing Spindle – This high-quality design results in super-precise spindle concentricity, with less than 0.05mm deviation, and minimal vibration.
• The Angle Grinder features a versatile application for grinding, including a depressed disc.

Specification:

• 0.5HP Die Grinders
• Grinding Wheel: 2 inch
• Net Weight: 1.5(0.7) lbs(kgs)
• Length: 7(178) in.(mm)
• Free Speed: 15000 rpm
• Air Inlet Size: 1/4 inch-NPT/PT
• Min. Hose Size: 3/8(10) inch(mm)
• Avg. Air Cons.: 3.5 cfm
