ZDG-S215 – Industrial 1/4 inch Air Die Grinder
Precision, Power, and Durability in a Compact Design
The ZDG-S215 Industrial 1/4-inch Air Die Grinder is a high-performance pneumatic tool designed for precision grinding, polishing, deburring, and surface preparation in the metalworking, automotive, aerospace, and maintenance industries. Its ergonomic design, robust construction, and consistent high-speed motor ensure efficiency and reliability in demanding industrial environments.
Key Features
High-Speed Industrial Motor – Delivers consistent RPM for fast material removal and fine finishing.
1/4 inch Collet Capacity – Supports a wide range of burrs, abrasives, and mounted points.
Compact and Ergonomic – A lightweight design reduces operator fatigue and enables work in tight spaces.
Durable Construction – Heavy-duty housing withstands industrial wear and tear.
Rear Exhaust Design – Keeps work surfaces clean by directing air away from the operator and material.
Vibration-Optimized Grip – Provides comfort for extended periods of operation.
Benefits
Efficient Performance – Rapid material removal with precision finishing.
Ergonomic & Lightweight – Reduces fatigue in long-duration tasks.
Durable Design – Built for heavy-duty industrial applications.
Versatile Tooling – Compatible with multiple accessories for grinding, polishing, and deburring.
Cleaner Operation – Rear exhaust maintains a safer and cleaner working environment.
Applications
Metal Fabrication – Edge finishing, deburring, and chamfering.
Automotive Repairs – Porting, polishing, and gasket removal.
Aerospace & Shipbuilding – Precision grinding in tight or complex spaces.
Maintenance & Industrial Repair – All-purpose surface preparation and finishing.
Why Choose the ZDG-S215?
The ZDG-S215 Industrial 1/4 inch Air Die Grinder is engineered for professionals who require power, precision, and durability. Its compact design, high-speed performance, and industrial-grade construction make it ideal for workshops, factories, and maintenance teams seeking a reliable and versatile die grinder for challenging applications.
- High-power, efficient motor for heavy grinding work.
- Side exhaust.
- Roll-type throttle.
- Compact and durable steel housing for long service life.
Specification:
- Size of Collet: 1/4(6) inch(mm)
- Free Speed: 24,000 rpm
- Operating Air Pressure: 90(6.2) PSI(bar)
- Avg. Air Consumption: 7.8(220) cfm(l/min)
- Net Weight: 1.46(0.66) lbs(kgs)
- Overall Length: 6-11/16(170) inch(mm)
- Min. Hose Size: 3/8(10) inch(mm)
- Air Inlet Size: 1/4 inch-NPT/PT
| Model | Size of Collet inch(mm) | Free Speed rpm | Operating Air Pressure psi(bar) | Avg. Air Consumption cfm(l/min) | Net Weight lbs(kgs) | Overall Length inch(mm) | Minch Hose Size inch(mm) | Air Inlet Size inch-NPT/PT |
| ZDG-S215 | 1/4(6) | 24000 | 90(6.2) | 7.8(220) | 1.46(0.66) | 6-11/16(170) | 3/8(10) | 1/4 |
| ZDG-S24B | 1/4(6) | 24000 | 90(6.2) | 7.8(220) | 1.7(0.77) | 7-3/64(179) | 3/8(10) | 1/4 |
