ZF-1MT Low Vibration Mini Air Lapper – Compact Precision with Safety Trigger
The ZF-1MT Low Vibration Mini Air Lapper is expertly crafted for fine lapping and polishing tasks, offering unparalleled precision in a compact form factor. Designed with operator safety and comfort in mind, this tool incorporates a low-vibration mechanism and a safety trigger for reliable and controlled operation. It is ideal for intricate toolmaking, mold crafting, and precision engineering tasks.
Key Features:
- Low Vibration Technology
- Minimizes hand-arm vibration, ensuring operator safety and comfort during prolonged use.
- Enhances precision and reduces fatigue.
- Safety Trigger Mechanism
- Prevents accidental activation, ensuring safe operation in demanding environments.
- Enhances control for delicate surface finishing.
- Miniature Compact Design
- Perfect for intricate and detailed work in confined spaces.
- Lightweight and ergonomically designed for ease of use.
- High-Performance Efficiency
- Delivers smooth, consistent strokes for exceptional surface finishing.
- Compatible with a variety of lapping and polishing accessories.
- Durable Construction
- Engineered for robust industrial use with high-quality materials for extended tool life.
Specifications:
- Stroke Length: Optimized for precision micro-lapping applications.
- Vibration Level: Ultra-low vibration design for operator comfort and accuracy.
- Safety Mechanism: Built-in safety trigger to comply with industrial safety standards.
- Weight: Lightweight design for maneuverability and reduced user strain.
- Applications: Suitable for precision lapping on metals, ceramics, and fine materials.
Applications:
- Mold and Die Crafting
- It is ideal for lapping and polishing intricate mold details.
- Aerospace and Automotive Industries
- Suitable for high-precision finishing tasks on delicate components.
- Tool and Die Manufacturing
- Efficiently refines intricate tooling surfaces for superior results.
- Electronics Manufacturing
- Perfect for polishing and finishing delicate electronic components.
- General Maintenance
- Versatile for a variety of lapping and finishing needs in industrial maintenance.
Why Choose the ZF-1MT Low Vibration Mini Air Lapper?
The ZF-1MT stands out with its low-vibration operation, safety-oriented design, and miniature build, making it the preferred choice for professionals tackling intricate and precision-demanding projects. Its balance of performance, safety, and ergonomic convenience ensures consistent results while reducing operator fatigue.
Achieve flawless surface finishes with the ZF-1MT Low Vibration Mini Air Lapper—the ultimate tool for precision and control in miniature lapping tasks.
Features
- High frequency with 1mm, 5mm & 10mm strokes for various kinds of surface finishing works such as precise and delicate lapping of die & mold surface, finishing in confined areas, and general filing works.
- Designed with the following patents to ensure extremely low vibration and operator’s comfort.
。Portable Pneumatic Tool assembled with module units.
。Suspension Vibration-Reducing means for portable pneumatic tools. - Throttle-type flexible hose equipped for the best maneuverability of the tool.
- Adjustable side exhaust directs air away from operators.
- Rubber sleeve designed for operator’s comfort.
- Operating Module
- Rubber Sleeve
- Suspension Damping Spring
- Directional Air Exhaust
- Rotary Switch
- Air Inlet Module
All rotary-type Switches can be converted to safety lever-type Switches upon request.
Features
- It is ideal for precise and delicate filing castings and lapping die and mold surfaces.
- High frequency with 0.5~1mm stroke for ZF-1, ZF-1T, ZF-1M, ZF-1MT
- High frequency with 3~5mm stroke for ZF-5, ZF-5T, ZF-5M, ZF-5MT
- High frequency with 7~10mm stroke for ZF-10, ZF-10T, ZF-10M, ZF-10MT
Specification:
- Blows Per Minute: 21000 bpm
- Stroke Length: 0.5~1 mm
- Avg. Air Cons.: 4(120) cfm(l/min)
- Net Weight: 0.73(0.33) lbs(kgs)
- Air Inlet Size: 1/4 inch-NPT/PT
- Min. Hose Size: 3/8(10) inch(mm)
- Vibration: 0.8 m/s2
- Sound Pressure: 72 dB(A)
Diamond File For ZF-1, ZF-1T, ZF-1M, ZF-1MT Type Air Lapper, 3mm Shank Diameter
201952
2mm Rectangular Diamond File
201954
4mm Rectangular Diamond File
201956
6mm Rectangular Diamond File
Hard Sponge Sandpaper block
- SB120-5 #120 100mm x 70mm x 25mm
- SB180-5 #180 100mm x 70mm x 25mm
- SB220-5 #220 100mm x 70mm x 25mm
- SB280-5 #280 100mm x 70mm x 25mm
COMPARISON CHARTS WITH COMPETITIVE DESIGNS ARE AVAILABLE UPON REQUEST.
| Model | Blows Per Minute bpm | Stroke Length mm | Avg. Air Cons. cfm(l/min) | Net Weight lbs(kgs) | Air Inlet Size inch-NPT/PT | Minch Hose Size inch(mm) | Vibration m/s² | Sound Pressure dB(A) |
| ZF-1 | 21000 | 0.5~1 | 4(120) | 1.26(0.57) | 1/4 | 3/8(10) | 0.8 | 72 |
| ZF-1T | 21000 | 0.5~1 | 4(120) | 1.26(0.57) | 1/4 | 3/8(10) | 0.8 | 72 |
| ZF-5 | 11000 | 3~5 | 2.82(80) | 1.54(0.7) | 1/4 | 3/8(10) | 3.6 | 83 |
| ZF-5T | 11000 | 3~5 | 2.82(80) | 1.54(0.7) | 1/4 | 3/8(10) | 3.6 | 83 |
| ZF-10 | 9000 | 7~10 | 3.89(110) | 1.65(0.75) | 1/4 | 3/8(10) | 4.6 | 71 |
| ZF-10T | 9000 | 7~10 | 3.89(110) | 1.65(0.75) | 1/4 | 3/8(10) | 4.6 | 71 |
| ZF-1M | 21000 | 0.5~1 | 4(120) | 0.73(0.33) | 1/4 | 3/8(10) | 0.8 | 72 |
| ZF-1MT | 21000 | 0.5~1 | 4(120) | 0.73(0.33) | 1/4 | 3/8(10) | 0.8 | 72 |
| ZF-5M | 11000 | 3~5 | 2.82(80) | 0.73(0.33) | 1/4 | 3/8(10) | 3.6 | 83 |
| ZF-5MT | 11000 | 3~5 | 2.82(80) | 0.73(0.33) | 1/4 | 3/8(10) | 3.6 | 83 |
| ZF-10M | 9000 | 7~10 | 3.89(110) | 0.73(0.33) | 1/4 | 3/8(10) | 4.6 | 71 |
| ZF-10MT | 9000 | 7~10 | 3.89(110) | 0.73(0.33) | 1/4 | 3/8(10) | 4.6 | 71 |
*Operating Air Pressure: 90psi/6.2bar
