ZHR-10 Spring Balancer
The ZHR-10 Spring Balancer is a high-quality load-support device engineered to provide weightless tool handling, ergonomic support, and improved operator safety in assembly, production, and maintenance environments. Designed to counterbalance the weight of suspended tools, the ZHR-10 allows smooth vertical movement with minimal operator effort, significantly reducing fatigue and improving work precision. Constructed with high-strength aluminum housing, precision coil springs, and adjustable tension control, the ZHR-10 delivers consistent performance and long-term reliability. It is an essential accessory for torque wrenches, pneumatic tools, electric screwdrivers, and assembly fixtures, particularly in continuous production or repetitive assembly operations.
Key Features
Load Capacity up to 10 kg – Designed to balance tools or equipment ranging from light to medium weight.
Adjustable Spring Tension – Fine-tuned load balancing allows precise adjustment according to tool weight.
High-Durability Construction – Heavy-duty steel wire and precision-wound spring ensure long operational life.
Smooth Vertical Travel – Enables effortless tool movement within the working range without sudden jerks.
Safety Lock Mechanism – An integrated fall-prevention system provides operator protection in the event of spring breakage.
Aluminum Alloy Housing – Lightweight, corrosion-resistant, and impact-resistant for industrial environments.
Compact, Easy-Mount Design – Simple top-hook or bracket mounting for flexible workstation installation.
Cable Stopper Adjustment – Limits tool travel distance for improved control and operator comfort.
Maintenance-Free Operation – Pre-lubricated spring and enclosed housing reduce wear and servicing needs.
Applications
The ZHR-10 Spring Balancer is widely used in industrial and manufacturing workstations where repetitive tool handling requires precision and comfort, including:
Assembly lines – supporting pneumatic or electric screwdrivers, riveters, and torque tools.
Automotive manufacturing – suspending power tools for wheel or engine assembly operations.
Electronics and appliance production – reducing operator strain during fine assembly work.
Aerospace and mechanical workshops – balancing specialized equipment for maintenance or calibration.
General manufacturing – supporting grinders, drills, and inspection instruments to improve ergonomics and safety.
Performance Advantages
Ergonomic Efficiency – Reduces operator fatigue and improves accuracy by eliminating resistance to tool weight.
Enhanced Safety – Built-in anti-fall mechanism prevents tool drop, protecting both users and equipment.
High Reliability – Robust spring and cable mechanism ensure stable, long-term balancing performance.
Productivity Improvement – Enables faster tool positioning and consistent workflow.
Low Maintenance – The enclosed design minimizes exposure to dust and debris, thereby extending service life.
Technical Benefits
Model: ZHR-10
Load Capacity: 5–10 kg (adjustable range)
Cable Travel: Approx. 1.3 meters (varies by configuration)
Housing Material: Aluminum alloy or high-strength steel
Suspension Hook: Forged steel with safety latch
Cable Material: Braided stainless-steel wire
Safety Device: Internal ratchet lock or secondary wire (anti-fall feature)
Spring Type: High-tension coil spring with sealed lubrication
Mounting Method: Overhead suspension hook or bracket installation
Finish: Corrosion-resistant powder coating
Operating Environment: 0°C to +50°C; indoor industrial use
Why Choose ZHR-10 Spring Balancer
The ZHR-10 Spring Balancer embodies commitment to ergonomic innovation and industrial reliability. Designed to reduce operator effort and enhance safety, it offers precision load balancing, robust construction, and long-term performance for daily production environments. By integrating the ZHR-10 into your workstation, you achieve improved operator comfort, productivity, and tool handling efficiency — all backed by engineering quality and proven industrial performance. Built on the principles of Power, Precision, and Productivity, the ZHR-10 is the perfect companion for modern assembly and manufacturing operations where safety, balance, and durability matter most.
