ZAR0921 – 3/16-inch Air Riveter
Precision Pneumatic Riveting for Professional Use
The ZAR0921 3/16-inch Air Riveter is a reliable, high-efficiency pneumatic tool designed for easy installation of blind rivets. Its compact build, strong air-driven power, and ergonomic form make it ideal for automotive work, sheet metal fabrication, maintenance tasks, and industrial assembly.
Key Features
3/16-inch Rivet Capacity – Supports standard blind rivets commonly used in metalwork, HVAC, automotive panels, and general assembly.
Pneumatic Operation – Powered by compressed air to deliver a consistent pulling force and fast, repeatable cycles.
Lightweight & Ergonomic Design – Built for comfort and reduced fatigue during prolonged use, especially in overhead or tight-space work.
Durable Construction – Manufactured with rugged materials for long-lasting industrial reliability.
Fast Operation – Optimized for quick and efficient rivet installation, boosting job-site productivity.
Simple Maintenance – Straightforward internal design makes servicing and parts replacement easier.
Technical Specifications
Model: ZAR0921
Rivet Size: 3/16 inch (4.8 mm) blind rivets
Tool Type: Pneumatic Riveter
Operation: Air-powered pull mechanism
Weight: Lightweight for maneuverability
Housing: Alloy or steel construction
Air Supply Requirement: Standard shop compressed air pressure
Benefits
Consistent & Secure Fastening – Ensures high-quality rivet installations with every stroke.
Reduced Operator Fatigue – Ergonomic balance and manageable weight make long jobs easier.
Low Total Cost of Ownership – Durable build with easy maintenance keeps downtime and repair costs low.
Versatile Use Cases – Ideal for workshops, assembly lines, and on-site applications.
Fast Cycle Times – High throughput ensures a steady and efficient workflow.
Applications
Automotive & Body Repair – Panels, brackets, and structural components.
HVAC & Ductwork – Riveting sheet metal seams and flange connections.
Light Industrial Fabrication – Enclosures, metalwork, and sheet assembly.
Maintenance & Repair Shops – Fast, reliable tool for general service tasks.
Prototype & Custom Fabrication – Precise riveting in small batches or one-off builds.
Why Choose the ZAR0921?
The ZAR0921 3/16-inch Air Riveter offers an excellent blend of performance, durability, and user comfort. It’s designed for professionals who need to reliably install rivets with speed and consistency while working in confined or complex assemblies. If you aim for ruggedness, efficiency, and long-term dependability in riveting, the ZAR0921 is a strong choice.
Features
- Sets 3/32″ to 3/16″ rivets with up to 1983 lbs. of pulling capacity
- Tougher and durable
- Easy operation
- Aluminum housing, strong & lightweight.
- Structured, easy to service.
- Powered by air only, no need to refill hydraulic oil.
- Quick cycle times, 2.0 seconds on average.
Specification:
- Traction Power: 1896(860) lbf(kgf)
- Stroke Length: 3/4(19) inch(mm)
- Net Weight: 3.1(1.4) lbs(kgs)
- Operating Air Pressure: 60~90 PSI
- Avg. Air Cons.: 0.03 cu.ft/stroke
- Min. Hose Size: 3/8(10) inch(mm)
- Sound Pressure: 79 dBA
- Vibration: <2.5 m/s2
- Nosepieces Equipped: 3/32(2.4)1/8(3.2)5/32(4.0)3/16(4.8)inch(mm)
| Model | Traction Power lbf(kgf) | Stroke Length inch(mm) | Net Weight lbs(kgs) | Operating Air Pressure psi(bar) | Avg. Air Cons. cu.ft/stroke | Min. Hose Size inch(mm) | Sound Pressure dB(A) | Vibration m/s² | Nosepieces Equipped inch(mm) |
| ZAR0921 | 1896(860) | 3/4(19) | 3.1(1.4) | 60~90 | 0.03 | 3/8(10) | 79 | <2.5 | 3/32(2.4)1/8(3.2) 5/32(4.0)3/16(4.8) |
| ZAR0921V | 1896(860) | 3/4(19) | 3.1(1.4) | 60~90 | 0.03 | 3/8(10) | 79 | <2.5 | 3/32(2.4)1/8(3.2) 5/32(4.0)3/16(4.8) |
| ZAR0818 | 1763(800) | 23/32(18) | 3.3(1.5) | 60~110 | – | 3/8(10) | 81 | <2.5 | 3/32(2.4)1/8(3.2) 5/32(4.0)3/16(4.8) |
| ZAR0818V | 1763(800) | 23/32(18) | 3.3(1.5) | 60~110 | – | 3/8(10) | 81 | <2.5 | 3/32(2.4)1/8(3.2) 5/32(4.0)3/16(4.8) |
